Features

● Equipped with a proprietary detachment mechanism (Patent No. 4126074).

● Built-in fail-safe mechanism.

● Piston operation confirmation sensor can be installed (optional).

Specifications

● Mounting position: Robot side

● Load capacity (kg): Up to 230

● Operating air pressure: 0.5–0.7 MPa

● Attachable/Detachable mechanism: Double-acting type

● Attachable/Detachable piping (mm): Outer diameter φ6

● Piping connection (mm): 10-Rc 3/8

● Mounting screws (mm): 6-M10

● Mounting pitch (mm): P.C.D. 160

● Positioning pin holes (mm): 4-φ10
